Classic style Stable Quality 125KHz 13.56MHz RFID Single door Access Control system with Keypad
Overview:
NT-260 is a numeric digital access control keypad specially designed for Electric Locking and access control security systems, has both multiple individual codes and single common code models for customers option; choose to press # or choose automatic code verification by entering passwords. Keypads can work with exit buttons, door bell keypads are also equipped with some security tools like self-locking and Tamper alarming, programming on the keypad itself. Easy operation, simple programming convenient use and reliable quality makes NT-260 a perfect choice for applications in office, real estates, factories etc.
Technical Specification
| Model | NT-260 Access Control Keypad |
| Voltage | 12V DC |
| Operating Current | 100mA |
| Access Control Interface | Electric lock, Door sensor, Exit button, alarm, DoorBell |
| User Code Combinations | 1 common user password, 250 multiple password for individual users |
| Operating Temperature | -20ºC - 60ºC |
| Operating Humidity | 20% - 80% |
| Dimensions | 117Lx74Wx40D(mm) |
| Weight | 0.24kg |
✔ Simple Programming & Easy Operation digital access control keypad.
✔ Adopting steadily working card reader technology.
✔ Security Auto-Lock: Keypad Locks for 30 Seconds After 10 False Entries.
✔ Versatile Connectivity: Can be Connected with Door-open Button and Doorbell.
✔ Data Safety: Non-volatile Memory ensures data retention upon Power Failure.
✔ Anti-Tamper: Tamper Switch available for Security Alarm System connection.
Frequently Asked Questions
● What RFID frequencies does the NT-260 support?
The system supports both 125KHz and 13.56MHz RFID frequencies for high compatibility.
● How many users can the access control system store?
It supports 1 common user password and up to 250 individual multiple passwords.
● Does the device have an alarm for unauthorized tampering?
Yes, it features a built-in Tamper Switch that can be connected to a security alarm system.
● What is the effective card reading distance?
The stable reading distance ranges from 1 to 5 meters depending on the environment.
● Will I lose my programmed data if the power goes out?
No, the NT-260 uses non-volatile memory to ensure all settings and codes are retained during power failure.
● Can this keypad be used outdoors?
It operates in temperatures from -20ºC to 60ºC; however, for outdoor use, we recommend professional installation with proper weather protection.
